• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1979 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 356881

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Video-Taperecorder/-Player

• Power type and voltage
• Alternating Current supply (AC) / 50 Hz, 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Video-Cassetten-Recorder N1702 /20 - Philips - Österreich

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 560 x 160 x 375 mm / 22 x 6.3 x 14.8 inch

• Notes

• Philips Video-Cassetten-Recorder  VCR Long-Play N1702 /20.

  Playback/Record-Zeit  3 Stunden mit LCV 180 Cassette.

  Siehe auch Philips N1702 /00 /15 /43 /45 /65. Die Ausführung N1702 /20 unterscheidet sich durch andere Einzelteile im Abstimmteil.

• Net weight (2.2 lb = 1 kg)
• 16 kg / 35 lb 3.9 oz (35.242 lb)

• Author
• Model page created by Jacky Blaise. See "Data change" for further contributors.
