• Country
• France

• Manufacturer / Brand
• Phrynis (Odéon), Industrie Musicale, Industrie Moderne, Ullmann; Paris

• Year
• 1938 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 228829

• Number of Tubes
• 5

• Valves / Tubes
• 6A8 6K7 6J7 25L6G CY2

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 cm = 4.7 inch

• Power out
• 2 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Inconnu - Unknown 1 - Phrynis Odéon, Industrie

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 230 x 170 x 130 mm / 9.1 x 6.7 x 5.1 inch

• Notes

• Case similar to Radialva Groom 39 (TRF, 4 tubes).

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 12 models, 11 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Phrynis (Odéon), Industrie Musicale, Industrie Moderne, Ullmann; Paris
