• Country
• France

• Manufacturer / Brand
• Phrynis (Odéon), Industrie Musicale, Industrie Moderne, Ullmann; Paris

• Year
• 1935 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 254476

• Number of Tubes
• 6

• Valves / Tubes
• CK1 CF3 CBC1 CL2 CL2 CY2

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (MW) and Long Wave.

• Details
• Visual Tuning Indicator pre Eye

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Odeon Senior [tous courants] - Phrynis Odéon, Industrie

• Shape
• Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.

• Dimensions (WHD)
• 450 x 500 x 280 mm / 17.7 x 19.7 x 11 inch

• Notes

• L'attribution à la marque Odéon n'est pas absolument certain.

• Net weight (2.2 lb = 1 kg)
• 14.8 kg / 32 lb 9.6 oz (32.599 lb)

• Author
• Model page created by Ernst Kranzl. See "Data change" for further contributors.

• Other Models

• Here you find 12 models, 11 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
