Integrated Stereo Amplifier A-119
Pioneer Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Pioneer Corporation; Tokyo
- Year
- 1991/1992
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 218664
- Number of Transistors
- Semiconductors present.
- Semiconductors
- STK4152
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 220-230/240; 240; 110/120-127/220/240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 50 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Integrated Stereo Amplifier A-119 - Pioneer Corporation; Tokyo
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 420 x 98 x 282 mm / 16.5 x 3.9 x 11.1 inch
- Notes
-
A hi-fi stereo integrated amplifier housed in a black metal case with continuous power output of 2 x 25 watts into 8 ohms from 30Hz to 20,000Hz with 0.2% total harmonic distortion (30 + 30 watts into 8 ohms, DIN). With Bass and Treble tone controls, Loudness switch, 2-way tape dubbing and a jack for Headphones. RCA phono sockets for input PHONO, TUNER and CD, for input/output DAT/TAPE and ADAPTOR/TAPE-2 and terminals for 1 pair of loudspeakers. The General Export model has 3 AC outlets.
2 x 30 Watt Sinusleistung DIN (8 Ohms).
Same as the earlier Pioneer A-115 Stereo Amplifier apart from appearance.
Specification Continuous power output
(both channels driven at 30Hz—20kHz)
THD 0.2 %, into 8Ω
25W + 25WDIN Continuous power output
(both channels driven at 1kHz)
THD 1.0 %, into 8Ω
30W + 30WTotal harmonic distortion
30Hz—20kHz, 25W, 8Ω
0.2%Input sensitivity/impedance
PHONO (MM)
CD, TUNER, DAT/TAPE1, ADPT/TAPE2
2.5mV/50kΩ
150mV/50kΩOutput level/impedance
TAPE REC, ADPTOR OUTPUT
150mV/2.2kΩFrequency response
PHONO (MM)
CD, TUNER, DAT/TAPE1, ADPT/TAPE2
30Hz—20kHz + 0.5dB
10Hz—50kHz +1dB,-3dBSignal-to-Noise ratio
(IHF short circuit, A network)PHONO (MM, 5mV input)
CD, TUNER, DAT/TAPE1, ADPT/TAPE277dB
95dBSignal-to-Noise ratio
(DIN, continuous power/50mW)PHONO (MM)
CD, TUNER, DAT/TAPE1, ADPT/TAPE263dB/60dB
81dB/62dBVersions/Power requirements
HEWZ Germany 220-230V, 240V AC 50/60Hz (switchable) HE Europe 220-230V, 240V AC 50/60Hz (switchable) HB UK 220-230V, 240V AC 50/60Hz (switchable) YPW Australia 240V AC 50/60Hz SD General 110V,120V-127V,220V,240V AC 50/60Hz with voltage selector Power Consumption: 210 watts
UK model Dimensions WHD: 420 x 103 x 282 mm
- Net weight (2.2 lb = 1 kg)
- 4.6 kg / 10 lb 2.1 oz (10.132 lb)
- Source of data
- -- Original prospect or advert
- Mentioned in
- - - Manufacturers Literature (1992 Pioneer Hi-Fi Components catalogue)
- Literature/Schematics (1)
- - - Manufacturers Literature (Service manual Pioneer A-119 A-229 dated Mar 1991 refers to A-115)
- Literature/Schematics (2)
- - - Manufacturers Literature (Operating Instructions Pioneer A-229 A-119)
