- Country
- France
- Manufacturer / Brand
- Pygmy, Ciate-Pygmy (SCIP, CIATE); Paris, La Plaine St. Denis, La Courneuve
- Year
- 1971 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 347542
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 480/10700 kHz
- Wave bands
- Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 110; 220 / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 1750 - Pygmy, Ciate-Pygmy SCIP, CIATE
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 295 x 195 x 90 mm / 11.6 x 7.7 x 3.5 inch
- Author
- Model page created by Didier Tholomier. See "Data change" for further contributors.
- Other Models
-
Here you find 125 models, 93 with images and 34 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Pygmy, Ciate-Pygmy (SCIP, CIATE); Paris, La Plaine St. Denis, La Courneuve
