Digital Clock Radio

Radialva, Véchambre Frères; Asnières, Courbevoie, Saint-Denis

Data
Forum
Pictures
Collections

  • Year
  • 1976 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 252749

 Technical Specifications

  • Number of Transistors
  • 6
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Digital Clock Radio - Radialva, Véchambre Frères;
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 215 x 105 x 90 mm / 8.5 x 4.1 x 3.5 inch
  • Notes

  • Radialva Digital Clock Radio.

    Range of band:
    155 to 260 m (1935 to 1153,8 kHz), between MW and SW, in one range.

    Electromechanical clock: model Sankyo DT-40C.

    Made in Singapore.

  • Net weight (2.2 lb = 1 kg)
  • 0.890 kg / 1 lb 15.4 oz (1.96 lb)
