- Country
- France
- Manufacturer / Brand
- Radialva, Véchambre Frères; Asnières, Courbevoie, Saint-Denis
- Year
- 1938/1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 62702
wrong schematic printed in STR
Depliant 1938/1939
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 472 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19 cm = 7.5 inch
- Power out
- 2.8 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: V69 - Radialva, Véchambre Frères;
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 415 x 455 x 280 mm / 16.3 x 17.9 x 11 inch
- Notes
-
3 gammes d'ondes : OC de 18 à 52 m, PO de 195 à 565 m, GO de 800 à 2000 m. Antifading différé agissant sur les lampes 6A8 et 6K7. Prise pick-up et HP supplémentaire. Lampes de cadran : 2 x 6.5 V / 0.3 A.
Modèle spécial pour 25 périodes.
Le schéma montré dans la Schématheque est très probablement issu d'un modèle différent (lampes série E).
- Net weight (2.2 lb = 1 kg)
- 10.5 kg / 23 lb 2 oz (23.128 lb)
- Price in first year of sale
- 1,590.00 FFR
- External source of data
- Serge Laffont/Martin Renoth
- Circuit diagram reference
- La Documentation du Revendeur - Radio
- Literature/Schematics (1)
- Schémathèque Toute la Radio (STR) (No. 405)
- Literature/Schematics (2)
- -- Original prospect or advert (Gamme 1939)
- Other Models
-
Here you find 191 models, 156 with images and 60 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Radialva, Véchambre Frères; Asnières, Courbevoie, Saint-Denis
