Super Reporter
Radio Commercial; Paris
- Country
- France
- Manufacturer / Brand
- Radio Commercial; Paris
- Year
- 1953
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 130574
Radio vendu en kit.
Radio vendu en kit.
Pub 1953
Radio Constructeur et Dépanneur 1953
Radio vendu en kit avec cadran ARENA
Radio vendu en kit
Radio vendu en kit
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet. / Ø 19 cm = 7.5 inch
- Power out
- 5.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Super Reporter - Radio Commercial; Paris
- Notes
- Cadre orientable incorporé, ébénisterie en noyer verni. 2 x OC dont une bande étalée , 3 ébénisteries différentes pour le Super Reporter 7 lampes et le Super Reporter Push-Pull 8 lampes
- Literature/Schematics (1)
- Radio Constructeur et Dépanneur 1953
