Supervox 536A Luxe
Radio L.L. (Lucien Levy, LL Radio), S.A.E.D.R.A., Douglas; Paris
- Country
- France
- Manufacturer / Brand
- Radio L.L. (Lucien Levy, LL Radio), S.A.E.D.R.A., Douglas; Paris
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 92060
-
- alternative name: LL || Radio LL
Advert own coll.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Supervox 536A Luxe - Radio L.L. Lucien Levy, LL
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 320 x 430 x 210 mm / 12.6 x 16.9 x 8.3 inch
- Notes
-
2 gammes d'ondes de 200 à 2000 m. Présélecteur, antifading effiface. Changeur de tonalité. Prise pick-up.
Modèle spécial 25 - 50 périodes, supplément 50 Fr.
Ébénisterie en ronce de noyer.
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- Price in first year of sale
- 1,595.00 FRF
- Mentioned in
- -- Original prospect or advert (L'Est Républicain, 21.12.1935)
- Literature/Schematics (1)
- -- Original prospect or advert (Gamme 1936)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
