• Year
  • 1936/1937
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 307706

 Technical Specifications

  • Number of Tubes
  • 5
  • Valves / Tubes
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 517 - Radio-Rêve, M. Petitjean;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 425 x 360 x 210 mm / 16.7 x 14.2 x 8.3 inch
  • Notes
  • 2 gammes d'ondes. Antifading. Contrôle de tonalité. Prise de pick-up.

    Même modèle avec OC voir type 527.

  • Price in first year of sale
  • 750.00 FRF
  • Mentioned in
  • -- Original prospect or advert (Saison 1936-37)
