• Country
• Austria

• Manufacturer / Brand
• Radio Amateur, Monatsschrift für Radio, Tonfilm und Fernsehen (ÖRA); Wien

• Year
• 1927

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 222986

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes

• Main principle
• TRF with regeneration; Reaction

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Storage and/or dry batteries / 2 & 80 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Kurzwellenempfänger 20 bis 80 m Wellenlänge - Radio Amateur, Monatsschrift f

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 410 x 190 x 380 mm / 16.1 x 7.5 x 15 inch

• Notes
• Bauanleitung von Ing K. Heinrich. Röhrentypen nicht fixiert.

• Mentioned in
• Radio-Amateur Wien (RA, 46), (Österreichischer Radio Amateur, ÖRA) (5/1927)

• Author
• Model page created by Rudolf Müller. See "Data change" for further contributors.
