• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1975 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 283121

• • Brand: SFER

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 3

• Semiconductors
• BF494 BF495 BF495 TBA810 AA119 BA315 BA314 BZX79

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12-14 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: 22AN160 /00 - Radiola marque

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 165 x 43 x 87.5 mm / 6.5 x 1.7 x 3.4 inch

• Notes

• 2 gammes d'ondes : PO de 520 à 1605 kHz, et GO de 150 à 254 kHz.

  Coffret métal noir, façade moulée. Dimensions incluent la façade.

  Voir aussi modèle Philips 22AN160 /00.

• Mentioned in
• -- Original-techn. papers.
