RA112B
Radiola (marque)
- Country
- France
- Manufacturer / Brand
- Radiola (marque)
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 101686
-
- Brand: SFER
Chassis Bild aus dem Service Manual Radiola
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 128 kHz; 2 AF stage(s); Reflex
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Storage and/or dry batteries / 2 & 135 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: RA112B - Radiola marque
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 500 x 275 x 200 mm / 19.7 x 10.8 x 7.9 inch
- Source of data
- -- Original prospect or advert
- Author
- Model page created by John Koster. See "Data change" for further contributors.
- Other Models
-
Here you find 855 models, 565 with images and 276 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
