RA310A
Radiola (marque)
- Country
- France
- Manufacturer / Brand
- Radiola (marque)
- Year
- 1960
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 101876
-
- Brand: SFER
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RA310A - Radiola marque
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 337 x 175 x 185 mm / 13.3 x 6.9 x 7.3 inch
- Notes
- Chassis same as Philips B3F01A. Colours: bordeaux, dark grey or ivory.
- Source of data
- -- Collector info (Sammler)
- Mentioned in
- -- Original prospect or advert (Prospekt: "Radiola 1962" Seite 9)
- Author
- Model page created by John Koster. See "Data change" for further contributors.
