• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1945

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 103132

• • Brand: SFER

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH3 ECF1 CBL6 CY2

• Main principle
• Superheterodyne (common); ZF/IF 472 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110-130 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: RA538U - Radiola marque

• Shape
• Tablemodel, low profile (big size).

• Notes
• Equivalant à la PHILIPS « A448 U »

• Source of data
• Le grand livre de la TSF

• Author
• Model page created by John Koster. See "Data change" for further contributors.
