RA6072
Radiola (marque)
- Country
- France
- Manufacturer / Brand
- Radiola (marque)
- Year
- 1967/1968
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 112072
-
- Brand: SFER
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Valves / Tubes
- EBF89 PCL86 EF184 EF184 PCL85 EL183 PCF80 PCF80 PL504 PY88 GY86 PCC189 PCF801 unknown_Tube
- Number of Transistors
- 2
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
- Power out
- 1.5 W (unknown quality)
- from Radiomuseum.org
- Model: RA6072 - Radiola marque
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 600 x 485 x 220 mm / 23.6 x 19.1 x 8.7 inch
- Notes
- Transistors: 2× AF139.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
