RA68A

• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1937/1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 101606

• • Brand: SFER

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EK2 EF5 EBC3 EBL1 EM1 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 118 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: RA68A - Radiola marque

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 580 x 370 x 240 mm / 22.8 x 14.6 x 9.4 inch

• Notes

• Bouton de monoréglage. Montage à contre-réaction. Sélectivité variable. HP à cône de dispersion.

  Équivalent au Philips 750A, voir exécution -29.

• Price in first year of sale
• 3,350.00 FRF

• Mentioned in
• -- Original prospect or advert (Le Journal, 21.09.1937)

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur (Correspondance Philips - Radiola, Juillet-Août 1956)

• Author
• Model page created by John Koster. See "Data change" for further contributors.
