• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1963/1964

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 156870

• • Brand: SFER

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• ECC85 ECH81 EF89 EBF89 EM84 EAA91 ECC83 EL84 EL84 EZ81

• Number of Transistors
• 6

• Semiconductors
• AF126 AF126 AF126 OC75 OC75 AC127 AA119 OA200

• Main principle
• Superheterodyne (common); ZF/IF 452/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 165; 200; 220; 245 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 17 cm = 6.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: RA5210A/02 - Radiola marque

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 552 x 242 x 216 mm / 21.7 x 9.5 x 8.5 inch

• Notes

• 4 gammes d'ondes: GO, PO, OC, FM. Cadre antiparasites PO-GO. 2 claviers dont 1 de tonalité. Balance entre les 2 voies stéréo. Prises PU, Modulation, HP supplémentaire.

  Décodeur stéréo et indicateur stéréro à transistors.

  Diodes: 3x AA119, 3x OA200 (premiers modèles 2x OA 200).

  Le dépliant Radiola 1964 mentionne 9 diodes et dimensions de 702 x 255 x 225 mm.

• Mentioned in
• -- Original prospect or advert (Dépliant 1964)

• Literature/Schematics (1)
• - - Manufacturers Literature

• Literature/Schematics (2)
• Le grand livre de la TSF (Doctsf Ref 27081)

• Author
• Model page created by Jacky Parmentier. See "Data change" for further contributors.
