RT5467
Radiola (marque)
- Country
- France
- Manufacturer / Brand
- Radiola (marque)
- Year
- 1958 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 185028
-
- Brand: SFER
- Number of Tubes
- 24
- Valves / Tubes
- PCC84 PCF82 EF80 EF80 EF80 EF80 EB91 PL83 EF80 EF80 EBF80 PL82 EBF80 ECL80 PL82 PCF80 ECL80 PL81 PY81 DY86 PY82 PY82 EZ80 MW53-22
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: RT5467 - Radiola marque
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 640 x 570 x 500 mm / 25.2 x 22.4 x 19.7 inch
- Notes
- Radiola s/w Fernsehgerät mit 819 Zeilen. Zusatzeingang für Plattenspieler, Zusatzusgang für Lautsprecher.
- Source of data
- - - Data from my own collection
- Author
- Model page created by Martin Krüger. See "Data change" for further contributors.
