• Country
• France

• Manufacturer / Brand
• Radiomatic, S.F.R.T. (SFRT); Montreuil, Seine Saint Denise

• Year
• 1953

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 252278

• • alternative name: SFRT

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6BA6 6BE6 6BA6 6AV6 6AQ5 6X4

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: A2 [6BE6] - Radiomatic, S.F.R.T. SFRT;

• Shape
• Chassis only or for «building in»

• Notes

• Power supply and loudspeaker-amplifier in separate box.

  See also model A2 with ECH81

• Mentioned in
• -- Schematic

• Author
• Model page created by a member from D. See "Data change" for further contributors.

• Other Models

• Here you find 83 models, 78 with images and 14 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Radiomatic, S.F.R.T. (SFRT); Montreuil, Seine Saint Denise
