A2P avec 6AJ8

Radiomatic, S.F.R.T. (SFRT); Montreuil, Seine Saint Denise

Data
Forum
Pictures
Collections

  • Year
  • 1956
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 243761
    • alternative name: SFRT

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Number of Transistors
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 6 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: A2P [avec 6AJ8] - Radiomatic, S.F.R.T. SFRT;
  • Shape
  • Chassis only or for «building in»
  • Notes

  • Sensibilité:

    • PO: de 2µV à 5µV
    • GO: <4µV pour 500mW de sortie.

    Ampli de puissance en push pull.

    Impédance du transformateur de sortie: 2.15Ω (à 400Hz).

    Poids et dimensions:

    • Boîtier de commande: 2,5 kg, 179 x 63 x 210 mm.
    • Boîtier d'alimentation: 2,7 kg,  179 x 130 x 112 mm.
  • Literature/Schematics (1)
  • - - Manufacturers Literature
  • Author
  • Model page created by Jean Marchal. See "Data change" for further contributors.
