Automat Luxus FS1153 Nr. >7400
Radione (RADIO Nikolaus Eltz); Wien
- Country
- Austria
- Manufacturer / Brand
- Radione (RADIO Nikolaus Eltz); Wien
- Year
- 1961 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 106209
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Automat Luxus FS1153 [Nr. >7400] - Radione RADIO Nikolaus Eltz;
- Shape
- Tablemodel with Push Buttons.
- Notes
- Röhren teilweise mehrfach. Empfangsbereich VHF Band I+III, UHF Band IV+V.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
