• Country
• Austria

• Manufacturer / Brand
• Radione (RADIO Nikolaus Eltz); Wien

• Year
• 1957/1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 319463

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EM81 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 459/10420 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 3 Loudspeakers

• Power out
• 2.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Duplex-Register 58W [eckiges S/W Gehäuse] - Radione RADIO Nikolaus Eltz;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 550 x 350 x 265 mm / 21.7 x 13.8 x 10.4 inch

• Notes

• Siehe auch Radione Duplex-Register 58W mit abgerundetem Gehäuse und
  Radione Duplex-Register S/W in etwas anderer Ausführung.

• Net weight (2.2 lb = 1 kg)
• 9.6 kg / 21 lb 2.3 oz (21.145 lb)

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
