Jupiter 2 W
Radione (RADIO Nikolaus Eltz); Wien
- Country
- Austria
- Manufacturer / Brand
- Radione (RADIO Nikolaus Eltz); Wien
- Year
- 1960
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 319521
Prospektbild 1960
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 461/10420 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Jupiter 2 W - Radione RADIO Nikolaus Eltz;
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 620 x 335 x 250 mm / 24.4 x 13.2 x 9.8 inch
- Notes
-
Wie Radione Jupiter W aber anderes Gehäuse.
- Net weight (2.2 lb = 1 kg)
- 9.7 kg / 21 lb 5.9 oz (21.366 lb)
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (1)
- Museums Bote, Österr. (Radione Modellliste, Heft 55 Mai 1994)
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
