• Country
• France

• Manufacturer / Brand
• Radio Test; Paris

• Year
• 1955/1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 361017

• Number of Tubes
• 6

• Valves / Tubes
• ECH81 6BA6 EBF80 6BQ5 EM85 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Serenade 56 - Radio Test; Paris

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 460 x 280 x 210 mm / 18.1 x 11 x 8.3 inch

• Notes

• 2 OC dont une bande étalée.

• Author
• Model page created by Claude Boulet. See "Data change" for further contributors.

• Other Models

• Here you find 43 models, 33 with images and 25 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
