Cadre antiparasite universel
Radio Voltaire; Paris
- Country
- France
- Manufacturer / Brand
- Radio Voltaire; Paris
- Year
- 1951
- Category
- Antenna (Aerial) or Coupler
- Radiomuseum.org ID
- 262289
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- RF-Circuit or wave trap (separate, can also be an antenna with amp.)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 110 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Cadre antiparasite universel - Radio Voltaire; Paris
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 160 x 110 x 80 mm / 6.3 x 4.3 x 3.1 inch
- Notes
-
Cadre antiparasites universel avec amplificateur H.F.
Alimentation secteur "tout courant". Peut être alimenté sur un secteur jusqu'a 240V si on modifie la valeur de R1 et de l'ampoule du voyant. Il faut aussi mettre en place R2.
L'antenne orientable fait 460x250 mm.
- Price in first year of sale
- 4,350.00 FrF
- Mentioned in
- Le Haut-Parleur (No 889 page 132)
- Author
- Model page created by Jean Marchal. See "Data change" for further contributors.
