• Country
• France

• Manufacturer / Brand
• Recta; Paris

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 143669

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AT6 50B5 35W4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Gramrex TC5 - Recta; Paris

• Dimensions (WHD)
• 220 x 150 x 110 inch / 5588 x 3810 x 2794 mm

• Notes
• Ebénisterie vernie ou gainée, même coffret que le Rimrex TC5. Tous courants.

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur 1950

• Author
• Model page created by Raynal Aufils. See "Data change" for further contributors.
