Zoé Zetamatic P.P.6 (VI)
Recta; Paris
- Country
- France
- Manufacturer / Brand
- Recta; Paris
- Year
- 1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 289627
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Dry Batteries / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 0.3 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Zoé Zetamatic P.P.6 - Recta; Paris
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 260 x 190 x 100 mm / 10.2 x 7.5 x 3.9 inch
- Notes
-
Cadre ferrite incorporé. Haut-parleur ellitique modèle spécial inversé de 12 x 19 cm. Coffret gainée lavable, deux tons.
Ce récepteur était vendu en kit complet pour 24290 Fr ou en ordre de marche pour 32800 Fr. Supplément pour transistors allemands 2000 Fr.
Possibilité d'équipement avec les transistors suivants:
- T1 (oscillateur modulateur) : OC44, SFT108, OC410 ou 37T1
- T2, T3 (amplificateurs MF) : OC45, SFT106, OC390 ou 36T1
- T4 (préamplificateur BF driver) : OC71, SFT101, OC304 ou 922T1
- T5, T6 (amplificateurs final push-pull classe B) : OC72, SFT121, OC308 ou 988T1
- Price in first year of sale
- 32,800.00 FRF
- Mentioned in
- Le Haut-Parleur (N° 1014, Avril 1959, pages 47)
- Author
- Model page created by Jean-Pierre Ambroise. See "Data change" for further contributors.
