Domino SR28
Reela-Radio, Reela-Gees; Paris
- Country
- France
- Manufacturer / Brand
- Reela-Radio, Reela-Gees; Paris
- Year
- 1975 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 307532
- Number of Transistors
- 3
- Main principle
- Superheterodyne (common); ZF/IF 480 kHz
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Domino SR28 - Reela-Radio, Reela-Gees; Paris
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 220 x 108 x 40 mm / 8.7 x 4.3 x 1.6 inch
- Author
- Model page created by Didier Tholomier. See "Data change" for further contributors.
