• Country
• France

• Manufacturer / Brand
• LRD, La Radio de Demain - voir REP

• Year
• 1953 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 288903

• Number of Tubes
• 6

• Valves / Tubes
• ECH42 EF41 EAF42 EL41 EM34 GZ41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-230 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - Unknown 2 - LRD, La Radio de Demain - voir

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 485 x 315 x 190 mm / 19.1 x 12.4 x 7.5 inch

• Notes

• 2x OC dont une bande étalée (BE).

• Author
• Model page created by Maurizio Bacchini. See "Data change" for further contributors.

• Other Models

• Here you find 2 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from LRD, La Radio de Demain - voir REP
