• Country
• France

• Manufacturer / Brand
• Ribet et Desjardins (R-D); Paris, Montrouge - voir aussi Unic

• Year
• 1956 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 225946

• Number of Tubes
• 16

• Valves / Tubes
• EL84 EY86 EY81 EL81 ECC82 ECF80 ECL80 EF80 ECL80 EF80 EBF80 EF80 6U8 6BQ7 EF80 17PB4B

• Main principle
• Superheterodyne (common); ZF/IF 28000/39150 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Croix du sud 56M17 - Ribet et Desjardins R-D; Paris

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 470 x 500 x 480 mm / 18.5 x 19.7 x 18.9 inch

• Notes

• 819 lignes, 2 redresseurs OA70 et OA71.

  Voir aussi modèle Sagittaire 56M21 (en 54 cm).

• Price in first year of sale
• 131,039.00 francs

• Author
• Model page created by Michel Guigon. See "Data change" for further contributors.
