• Country
• France

• Manufacturer / Brand
• Ribet et Desjardins (R-D); Paris, Montrouge - voir aussi Unic

• Year
• 1966 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 226080

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors
• AF126 AF124 AF124 BF121 BF121 BF125 BC170 BC170 BC221 AC187 AC188

• Main principle
• Superheterodyne (common); ZF/IF 455 / 10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Batteries / addl. power jack / 8 x 1,5 (R20) / 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.5 W (2 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Milos - Ribet et Desjardins R-D; Paris

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• Ribet Desjardins Milos: Poste portable alimenté par 8 piles 1,5 V ou par 12 V DC (alimentation d'une voiture), prise antenne voiture commutable.

• Author
• Model page created by Michel Guigon. See "Data change" for further contributors.
