• Country
• France

• Manufacturer / Brand
• Unic-Radio - voir aussi Ribet-Desjardins; Montrouge

• Year
• 1948 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 271008

• Number of Tubes
• 4

• Valves / Tubes
• ECH3 ECF1 EBL1 5Y3GB

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 4834 - Unic-Radio - voir aussi Ribet-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 405 x 330 x 250 mm / 15.9 x 13 x 9.8 inch

• Notes

• Coffret bakélite, décor métallique.

• Net weight (2.2 lb = 1 kg)
• 7.5 kg / 16 lb 8.3 oz (16.52 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Manfred Rathgeb. See "Data change" for further contributors.

• Other Models

• Here you find 76 models, 72 with images and 15 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
