• Country
• Japan

• Manufacturer / Brand
• Roadstar; Japan

• Year
• 1999 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 120878

• • Brand: Roadstar El. GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• CD-Player, -Writer, MD, MOD (audio)

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 15 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: HRA-1500CD - Roadstar; Japan

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 320 x 220 x 210 mm / 12.6 x 8.7 x 8.3 inch

• Notes
• AM-FM retro design radio with CD player. Full coverage BC and FM bands. CD player with LED display. Without remote control.

• Net weight (2.2 lb = 1 kg)
• 4.3 kg / 9 lb 7.5 oz (9.471 lb)

• Price in first year of sale
• 91.00 Eur

• Source of data
• - - Data from my own collection

• Author
• Model page created by Danko Tkalec. See "Data change" for further contributors.

• Other Models

• Here you find 95 models, 93 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
