Portable Stereo Cassette Receiver RCR 301 N

Roadstar; Japan

Data
Forum
Pictures
Collections

  • Year
  • 1989 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 288473
    • Brand: Roadstar El. GmbH

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Portable Stereo Cassette Receiver RCR 301 N - Roadstar; Japan
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 295 x 125 x 90 mm / 11.6 x 4.9 x 3.5 inch
  • Notes

  • ROADSTAR PORTABLE Stereo Cassette Receiver mod. RCR 301N - controllo volume - antenna telescopica esterna - commutatore radio /tape/off - commutatore AM/FM - tasti pause/stop-eject/ff.ww./rew/play rec - microfono incorporato - uscita per cuffia - maniglia di trasporto - frequency range: MW: 540-1600 kHz - FM: 88-108 MHz - consumo: 8 watt.

    Roadstar International LTD./Dublin -EIRE.

    Made in CHINA.



  • Net weight (2.2 lb = 1 kg)
  • 1.1 kg / 2 lb 6.8 oz (2.423 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
