Freudenstadt 9

SABA; Villingen

Data
Forum
Pictures
Collections

  • Year
  • 1958/1959
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 21751
    • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 9
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/6750 kHz
  • Tuned circuits
  • 6 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 150; 220 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 7 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Freudenstadt 9 - SABA; Villingen
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 635 x 375 x 285 mm / 25 x 14.8 x 11.2 inch
  • Notes
  • Schallkompressor, drehbare Ferritantenne
  • Net weight (2.2 lb = 1 kg)
  • 14.1 kg / 31 lb 0.9 oz (31.057 lb)
  • Price in first year of sale
  • 449.00 DM
  • External source of data
  • Erb

 Collections | Museums | Literature

Collections

The model Freudenstadt is part of the collections of the following members.

Literature

The model Freudenstadt is documented in the following literature.

 Forum

Forum contributions about this model: SABA; Villingen: Freudenstadt 9

Threads: 3 | Posts: 19

Hallo Radio-Freunde,
  Erstens, bitte entschuldigen Sie meine schreckliche Deutsch.

Zweitens kann mir jemand helfen, mit der Druckknopf-Mechanismus von diesem Radio? Als ich die TA-Taste drücken, sperrt ihn in Position und nicht ausrasten, wenn ich irgend eine andere Taste drücken. Ich kann nicht sehen, wo das Problem liegt.
Hat jemand einen Vorschlag?
Mit freundlichen Grüßen,
Bob Isaac



(In case my German is so bad that no one can understand what I am asking, here it is in English:)

Hello radio Friends,

 Perahpas someone can help me?  Whenever I push the TA button on this radio, it locks into place and does not disengage when whenever I push another button. I have to work it up-and-down until it will finally release.  I cannot see where the problem is.

Does anyone have a suggestion about how I should go about finding and correcting the problem?

Bob Isaac, 04.Jan.11

Weitere Posts (3) zu diesem Thema.

Hello Friends,

 I recently purchased this radio. The chassis is in wonderful condition, but the cabinet is in sad shape.  With over 50% of the original finish missing, I decided to refinish the cabinet.  I carefully stripped off the remaining laquer, taking measurements and making notes as to the location of the three gold pinstripes.

I could not see a good way to remove either the plastic speaker covers on the sides nor the brass trim on the front side, so I left them in place and carefully worked around them.  I did make some surface scratches on the brass with the sand paper, but I'll buff them out with a polishing wheel on my Demel.  I also accidently got some stripper on the plastic which messed it up, but I'll bite the bullet and wear my fingers out buffing away the bad spots with Novus plastic polish.  Fortunately, I had wonderful results removing the grill cloth from the pressboard backing and cleaning it in the sink with some Woolite.  After it air-dried, I was able to stretch it back over the board fixing it in place with spray adhesive and staples.

I purchased some palisander colored wood stain and will top that with several coats of Tung oil. I also purchased some 2mm gold pinstripe stickers to replace the former pinstripes (which appeared to have been painted on?)

My question is this:  When should I apply the pinstripes?

1st thing?  After the toner? or after a coat or two of the Tung oil (laquer)?



Any other suggestions about what I have done or plan to do are also welcome.

Thank you!

Bob

Bob Isaac, 23.Dec.10

Weitere Posts (15) zu diesem Thema.

Hallo liebe Radiosammler und Experten

Ich bin seit gestern stolzer Besitzer eines Freudenstadt 9.
Ein übler Brumm bei aufgedrehtem Bassregler lies sich durch tauschen von EABC80 beseitigen.
Der UKW Empfang ist einwandfrei, L/M/K eher schwach.
Meine Sorge aber ist der Netztrafo, der meiner Meinung nach zu stark aufheizt.
Das Gerät ist sonst in einem guten Zustand und ich habe große Freude daran.
Für Hinweise und Ratschläge bin ich sehr dankbar.

LG Sven Hoffmann

Sven Hoffmann, 30.Apr.08

Weitere Posts (1) zu diesem Thema.
