• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1959/1960

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 25549

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 13

• Valves / Tubes
• EC92 EC92 ECH81 EF89 EM84 EBF89 EF86 EF86 EBC91 EABC80 ECL80 EL84 EL84

• Main principle
• ZF/IF 460/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer + Tape Recorder; Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 6 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Königin von Saba Automatic 100 St - SABA; Villingen

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 1920 x 950 x 490 mm / 75.6 x 37.4 x 19.3 inch

• Notes

• Fernseh-Chassis = Schauinsland T1005;
  Rundfunk-Chassis = Freiburg Automatic 100 Stereo;
  Phono-Chassis = Dual 1006;
  Tonband-Chassis (Mehrpreis 599,- DM) = Sabafon TC84.

  Mit Fernbedienung FS 700/1000 und Fernsteuerung RS 100.
  Abgleich (auch Steuerfilter)
  Alignment (also automatic filter)

  Die Röhrenbestückung und Netzspannungs-Angabe gilt nur für den Rundfunkteil.

• Net weight (2.2 lb = 1 kg)
• 146 kg / 321 lb 9.4 oz (321.586 lb)

• Price in first year of sale
• 3,250.00 DM

• Source of data
• HdB d.Rdf-& Ferns-GrH 1959/60
