Le Magnetone
Samas (Dictone); Paris
- Country
- France
- Manufacturer / Brand
- Samas (Dictone); Paris
- Year
- 1949
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 204370
Publicité (date inconnue)
Publicité (date inconnue)
- Number of Tubes
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Wire Recorder (or -Player)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
- Power out
- 4.5 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Le Magnetone - Samas Dictone; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 380 x 500 x 220 mm / 15 x 19.7 x 8.7 inch
- Notes
-
Enregistreur avec deux vitesses d'enregistrement. Ampli 6 lampes, puissance modulée 4,5 watts.
Possibilité de mixage, micro, radio, pick-up. Bras de pick-up spécial pour enregistrement des disques par repiquage direct, usage de l'appareil en pick-up normal (adaptation du plateau situé dans le couvercle et rajout du bras).
"Haute Fidélité Musicale" (100 à 10.000 pps).
- Net weight (2.2 lb = 1 kg)
- 18 kg / 39 lb 10.4 oz (39.648 lb)
- Price in first year of sale
- 83,500.00 FRF
- Mentioned in
- -- Original prospect or advert (TSF pour Tous, Juillet-Aout 1949)
- Author
- Model page created by Christian Berthier. See "Data change" for further contributors.
