- Country
- France
- Manufacturer / Brand
- Schneider (Frères, Radio-Télévision); Paris, Ivry / Seine
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 68661
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 480 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110, 125, 145, 220, 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Concerto - Schneider Frères, Radio-
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 560 x 370 x 340 mm / 22 x 14.6 x 13.4 inch
- Notes
- Lautsprecher nach oben gerichtet; 4 Skalenlämpchen; Bedienung: 4 Drehknöpfe vorne; abziehbares Netzkabel.
- External source of data
- Serge Laffont/Martin Renoth
