• Country
• France

• Manufacturer / Brand
• Schneider (Frères, Radio-Télévision); Paris, Ivry / Seine

• Year
• 1970

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 181996

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• AF106 AF125 BF234 BF234 BF234 SFT48 TO00104 AC141 AC142 BA110 AA143 BZX62 BZX68

• Main principle
• Superheterodyne (common); ZF/IF 457/10700 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / C: 6 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 0.7 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Major - Schneider Frères, Radio-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 300 x 190 x 73 mm / 11.8 x 7.5 x 2.9 inch

• Notes

• 3 gammes d'ondes : FM de 87 à 108 MHz, PO de 516 à 1630 kHz, GO de 152 à 275 kHz. Clavier 5 touches dont commutation Antenne et CAF. HP elliptique de 10 x 16 cm, Z = 13 Ω.

  Coffret plastique et matelassé.

  11 diodes, listées une fois par type.

• Net weight (2.2 lb = 1 kg)
• 1.850 kg / 4 lb 1.2 oz (4.075 lb)
