Silvertone 1948 Order= 57LM 1948

Sears, Roebuck & Co.; Chicago (IL)

Datos
Foro
Imágenes
Colecciones

  • Año
  • 1936
perfect model
  • Categoría
  • Radio - o Sintonizador pasado WW2
  • Radiomuseum.org ID
  • 56059
    • Brand: Silvertone

Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.

 Especificaciones técnicas

  • Numero de valvulas
  • 5
  • Principio principal
  • Superheterodino en general; ZF/IF 175 kHz; 3 Etapas de AF
  • Número de circuitos sintonía
  • 6 Circuíto(s) AM
  • Gama de ondas
  • OM, OL y OC
  • Tensión de funcionamiento
  • Baterías recargables o pilas / 2V or 3V & 135 Volt
  • Altavoz
  • Altavoz magnético (sin saber mas) / Ø 8 inch = 20.3 cm
  • Material
  • Madera
  • de Radiomuseum.org
  • Modelo: Silvertone 1948 Order= 57LM 1948 - Sears, Roebuck & Co.; Chicago
  • Forma
  • Consola en general
  • Ancho, altura, profundidad
  • 21.5 x 36.3 x 11 inch / 546 x 922 x 279 mm
  • Anotaciones

  • The Sears Silvertone 1948 is a battery operated 5 tube BC, Longwave and SW band receiver.  Has AGC and tone control. Uses 1G1 ballast when using 3V dry "A" batteries.  Also can use 2V Storage "A" batteries by replacing ballast tube with shorting jumper.

    Band Frequency Ranges are as follows:
    BC Band (Band B)..................545-1600kHz
    Longwave Band (Band A)........225-440kHz
    SW Band (Band C).................5.9-15.5MHz

    The chassis and schematic of this model is also used in Sears Silvertone model 1947.

    Catalog States: Streamline design cabinet, Fluted Side panels, Instrument panel is fine matched Claro walnut veneer; balanced, selected hardwoods; lustrous walnut finish.

    Order number 57LM 1948 with tubes and 6-month Dry "A" and three "B" batteries Cash Price $39.95 See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101).

  • Precio durante el primer año
  • 39.95 $
  • Ext. procedencia de los datos
  • Ernst Erb
  • Referencia esquema
  • Rider's Perpetual, Volume 8 = 1937 and before
