Djinn Inconnu
Sectrad; Paris
- Country
- France
- Manufacturer / Brand
- Sectrad; Paris
- Year
- 1958 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 282754
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- AC/DC-set / 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Djinn Inconnu - Sectrad; Paris
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 200 x 145 x 110 mm / 7.9 x 5.7 x 4.3 inch
- Notes
-
4 gammes d'ondes dont 1 bande étalée (BE) sur OC.
Voir aussi modèle Radio Lorraine Grillon.
- Net weight (2.2 lb = 1 kg)
- 1.4 kg / 3 lb 1.3 oz (3.084 lb)
- Author
- Model page created by Roberto Gabba. See "Data change" for further contributors.
- Other Models
-
Here you find 8 models, 8 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sectrad; Paris
