Emeraude
Sélecta; Tours, Bourg-la-Reine
- Country
- France
- Manufacturer / Brand
- Sélecta; Tours, Bourg-la-Reine
- Year
- 1950 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 220977
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Emeraude - Sélecta; Tours, Bourg-la-Reine
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 650 x 345 x 300 mm / 25.6 x 13.6 x 11.8 inch
- Notes
- Der Wellenschalter hat 11 Stellungen, davon 8 für Kurzwelle (7 gespreizte Bänder).
Spartrafoschaltung, Chassis kann unter Netzspannung stehen!
- Net weight (2.2 lb = 1 kg)
- 11 kg / 24 lb 3.7 oz (24.229 lb)
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
- Other Models
-
Here you find 5 models, 4 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sélecta; Tours, Bourg-la-Reine
Collections
The model Emeraude is part of the collections of the following members.
