• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1960–1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 82127

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Tuned circuits
• 9 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 110-240/ Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: FMA-22 - Sharp; Osaka

• Shape
• Tablemodel with Push Buttons.

• Notes
• Gerät ist für Strom sowie für Batterie ausgelegt

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.

• Other Models

• Here you find 1338 models, 1209 with images and 517 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Sharp; Osaka
