Transistor UHF Konverter 701240
Siemens-Austria (WSW); Wien
- Country
- Austria
- Manufacturer / Brand
- Siemens-Austria (WSW); Wien
- Year
- 1966 ??
- Category
- Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
- Radiomuseum.org ID
- 251439
-
- alternative name: Ges. für Technische Glaswaren
- Brand: Wiener Schwachstrom Werke (WSW)
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Transistor UHF Konverter 701240 - Siemens-Austria WSW; Wien
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 135 x 50 x 105 mm / 5.3 x 2 x 4.1 inch
- Notes
-
Band IV/V-Konverter auf VHF.
- Net weight (2.2 lb = 1 kg)
- 0.7 kg / 1 lb 8.7 oz (1.542 lb)
- Author
- Model page created by Bernhard Sacherer. See "Data change" for further contributors.
