• Country
• France

• Manufacturer / Brand
• Socradel, Société Française de Constructions Radio-Électriques; Paris, Courbevoie, Rueil-Malmaison

• Year
• 1939 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 331413

• Number of Tubes
• 5

• Valves / Tubes
• EK2 EF9 EBC3 EL3N 1883

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 100; 130; 150; 220; 240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 7 inch = 17.8 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - Unknown 4 - Socradel, Société Française de

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 410 x 250 x 210 mm / 16.1 x 9.8 x 8.3 inch

• Author
• Model page created by Victor Boj Cabistañ. See "Data change" for further contributors.
