Pulse Generator GO 1101

Solartron Laboratory Instruments Ltd.; Surrey

Dati
Forum
Immagini
Collezioni

  • Anno
  • 1962 ?
  • Categoria
  • Strumento da laboratorio
  • Radiomuseum.org ID
  • 329637

Clicca sulla miniatura dello schema per richiederlo come documento gratuito.

 Specifiche tecniche

  • Gamme d'onda
  • - senza
  • Tensioni di funzionamento
  • Alimentazione a corrente alternata (CA)
  • Altoparlante
  • - - Nessuna uscita audio.
  • Materiali
  • Mobile di metallo
  • Radiomuseum.org
  • Modello: Pulse Generator GO 1101 - Solartron Laboratory
  • Annotazioni

  • The pulse repetition rate of the GO 1101 is continuously variable from 10Hz to 500kHz, (2µsec to 100msec period), and can be controlled by internally or externally derived trigger pulses. The pulse amplitude is  adjustable over the range 0.5V to 100V, positive or over the range 0.5V to 100V, positive or negative-going, with switched selection of single or double-  pulse output. The duration of the main pulse can be set to any time between 1µsec and 100msec, and the incidence of the main pulse delayed on the pre-pulse by any period between 1µsec and 10msec. The negative-going edge of a 3V amplitude main pulse has a rise-time of less than 12nsec. Useful additional attributes are the ability to generate a square-wave signal over the frequency range 10Hz to 500kHz, and to square a sine-wave or approximate square wave input of any frequency between 25Hz and 5MHz. An external synchronization facility enables the GO 1101 to be employed as an oscilloscope sweep-delay generator or frequency divider.

  • Bibliografia
  • -- Original-techn. papers. (Electronic Engineering, volume 34, year 1962)
