Ranger

Sonolor; Paris, La Courneuve

Data
Forum
Pictures
Collections

  • Year
  • 1971 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 164897

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 484 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 2 × 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Ranger - Sonolor; Paris, La Courneuve
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 250 x 165 x 75 mm / 9.8 x 6.5 x 3 inch
  • Notes

  • 2 gammes d'ondes PO et GO. Clavier 3 touches dont commutation antenne-cadre. Cadre ferrite. Prise antenne voiture et écouteur ou HPS.

    Coffret gainé anti-choc.

    Équivalent au Vissaux Trouvère.

  • Mentioned in
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
