• Country
• France

• Manufacturer / Brand
• Sonora-Radio; Paris, Puteaux

• Year
• 1947 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 75829

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH3 EF9 EBF2 EL3 EM4 1883

• Main principle
• Superheterodyne (common); ZF/IF 472 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-250 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: CR 4 - Sonora-Radio; Paris, Puteaux

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 570 x 300 x 310 mm / 22.4 x 11.8 x 12.2 inch

• Net weight (2.2 lb = 1 kg)
• 15 kg / 33 lb 0.6 oz (33.04 lb)

• Author
• Model page created by Patrice Zeissloff. See "Data change" for further contributors.
