• Country
• France

• Manufacturer / Brand
• Sonora-Radio; Paris, Puteaux

• Year
• 1951–1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 75960

• Number of Tubes
• 6

• Valves / Tubes
• 6BE6 6BA6 6AT6 6AQ5 6AF7 6X4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19.5 cm = 7.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Élégance I - Sonora-Radio; Paris, Puteaux

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 490 x 275 x 24 mm / 19.3 x 10.8 x 0.9 inch

• Notes

• Gamme OC depuis 15 m. Contre-réaction.

  Supplément pour 25 périodes, 400 Fr.

• Price in first year of sale
• 29,450.00 FRF

• Mentioned in
• - - Manufacturers Literature (Tarif 15.01.1953)

• Literature/Schematics (1)
• -- Original prospect or advert

• Author
• Model page created by Patrice Zeissloff. See "Data change" for further contributors.

• Other Models

• Here you find 222 models, 172 with images and 119 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Sonora-Radio; Paris, Puteaux
